SSM 24 Block Plant with Steel Building Delivered to Khan Crete, Peshawar

A Complete Turnkey Solution – From Machine to Shelter

Khan Crete, a rising name in Peshawar’s construction materials market, had a vision. They wanted to produce high‑quality pavers, blocks, and curbstones – but not under the open sky. Peshawar’s weather can be brutal: scorching summer sun that bakes fresh concrete, and winter rains that halt production. They needed a complete protected facility, not just a block machine.

That’s when they approached Silver Steel Mills. And we didn’t just deliver a machine. We delivered a fully integrated production plant – including the SSM 24 block making machine, batching system, planetary mixer, conveyor belt, automatic stacker, and a custom‑designed steel building to cover it all.

The year was 2020. Despite the challenges of that year, we successfully installed the plant in Peshawar. Khan Crete started production on schedule – and they’ve never looked back.



---

The Challenge – Peshawar’s Weather Was the Real Enemy

Khan Crete’s site was open to the elements. In summer, the steel sheets of any machine would get too hot to touch. In winter, rain would turn their curing yard into a muddy mess. Their workers often had to stop production due to bad weather.

They needed:

• A weather‑protected plant – a roof over the machinery and work area.

• High production capacity – to serve Peshawar’s growing housing schemes.

• Consistent quality – pavers and blocks that meet Pak‑standard specs.

• Low maintenance – because sending technicians to Peshawar takes time.

After visiting our factory in Gujranwala and seeing a covered plant installation, Khan Crete decided to go with a complete turnkey solution from Silver Steel Mills.

---

The Solution – SSM 24 Plant + Steel Building

We designed, fabricated, delivered, and installed everything:

1. Main Block Machine – SSM 24

2. Batching System (Digital Weighing)

• 3 aggregate bins for sand, 6 mm crush, 10 mm crush.

• 50‑ton cement silo with dust collector.

• Digital load cells – accurate to ±0.5%.

3. Planetary Mixer

• Batch capacity : 1000 kg.

• Heavy‑duty blades for thorough mixing.

• Discharge into conveyor belt.

4. Conveyor Belt

• Length : 10 meters, rubber belt with cleats.

• Motor : 5 HP gear motor.

5. Automatic Stacker

• Pallet stacker with hydraulic lift.

• Reduces manual handling – only 2‑3 operators needed per shift.

6. Steel Building (Plant Cover)

This was the extra touch that made Khan Crete’s plant truly weather‑proof:

• Covered area : 2,500 sq. ft.

• Structure : I‑beams (Q345B steel) + galvanised purlins.

• Roof cladding : PPGI sheets (insulated option) to reflect heat.

• Height : 14 ft at eave – enough for machine maintenance and natural ventilation.

• Side walls : Partial open for air flow, but roof fully covers the machine, batching system, and mixer.

• Rain gutters to channel water away from work area.

The steel building was erected first, creating a shaded, dry workspace. Then we installed the machinery inside. Khan Crete’s workers now work comfortably – even on the hottest July afternoon or during monsoon showers.

---

Production Capacity – Real Numbers from Peshawar

Once commissioned, the SSM 24 plant consistently delivered (two shifts, 16 hours):

The batching system ensures every mix has exactly the right proportion of cement, sand, and crush – resulting in 5,000+ PSI strength for all products.

“We used to struggle with rain delays. A single shower could ruin a day’s production. Now, with the steel building, we work regardless of weather. The SSM 24 runs like a tank – strong, steady, and reliable. Silver Steel Mills didn’t just sell us a machine; they gave us a complete factory.”
– Owner, Khan Crete, Peshawar

---

Why the Steel Building Was a Game Changer

Khan Crete initially thought they could put up a simple tin shed themselves. But they realised that a proper engineered steel building offers:

• Durability – withstands Peshawar’s strong winds and occasional hail.

• Heat reflection – PPGI roof sheets reduce interior temperature by 8‑10°C.

• No rust – galvanised purlins and coated sheets.

• Quick erection – our team put up the building in under 10 days.

The cost of the steel building was recovered within months through zero weather‑related downtime and longer machine life (electronics protected from direct sun and moisture).

---

Financial Impact – A Smart Investment

Khan Crete now supplies pavers to DHA Peshawar, to private housing schemes, and to road contractors. Their reputation for consistent quality has grown because their production is no longer at the mercy of the weather.

---

A Partnership Beyond the Sale

Since 2020, Silver Steel Mills has supplied Khan Crete with additional moulds (special‑size curbstones for a commercial project) and replacement wear parts (mixer blades, conveyor belt). Their operators call us directly when they have questions – and we answer.

That’s the Silver Steel Mills difference: we don’t disappear after the machine is delivered.

---

Technical Snapshot – SSM 24 + Steel Building (Khan Crete)

---

Deploying Fully Integrated SSM 24 Block Plant with Batching System & Custom Steel Shed for Khan Crete, Peshawar

KPK ke capital aur mega commercial hub Peshawar aur iske mutasila ilaqon mein jab se infrastructure development, modern housing societies, aur road networks tezi se barh rahe hain, tab se high-strength concrete elements ki demand bohot high ho chuki hai. Year 2020 mein Silver Steel Mills (SSM) ne Peshawar ke leading concrete enterprise Khan Crete ke sath mil kar ek massive turnkey engineering project execute kiya. Silver Steel Mills ne Khan Crete ko unki production facility par apna high-performance SSM 24 Fully Automated Concrete Block & Paver Plant successfully deliver, fabricate, aur erect kar ke diya.

Is project ki sab se khaas baat yeh thi ke Silver Steel Mills ne Khan Crete ko sirf machinery supply nahi ki, balkay raw-material processing se lekar final weather-protection tak ek complete turnkey ecosystem khud manufacture aur design kar ke diya. Isme high-capacity automatic block manufacturing line, computerized aggregate batching plant, industrial mixer, heavy conveyor belts, aur poore setup ko barish (rain) aur teez dhoop (sunlight) se long-term protect karne ke liye customized Steel Shed / PEB Building bhi shamil thi.

🛠️ Complete Turnkey Plant Infrastructure & Automated System Components

Khan Crete Peshawar ka yeh engineering setup ek automatic manufacturing line hai, jise extreme weather resilience aur continuous high-speed production ke liye design kiya gaya hai:

• SSM 24 Heavy-Duty Main Machine Unit: High-frequency synchronized vibration aur heavy hydraulic compression technology se les main assembly, jo concrete components ko maximum structural density faraham karti hai. Is structural compaction ki waja se har block aur paver ka size uniform aur crushing strength market se kahin zyada high hoti hai.

• Computerized Automated Batching Plant: Raw materials (cement, graded sand, aggregates, aur water) ki exact proportioning khud karne ke liye precision sensors par mabni batching system, jo concrete mix ki commercial quality aur high-grade standards ko har batch mein exact barqarar rakhta hai.

• Industrial Concrete Mixer Machine & Conveyor Belt Matrix: Aggregates aur cement matrix ka ek perfectly homogeneous rich concrete paste tayar karne ke liye optimized heavy-duty mixer. Is mixed material ko bina kisi human interference ya delay ke directly main block machine ke feeding hopper tak safety ke sath transmit karne ke liye custom conveyor belts chalayi gayi hain.

• Custom Pre-Engineered Steel Shed Building (PEB Structure): Peshawar ke severe weather shifts, monsoon rains, aur intense summer sunlight se poori machinery line, electronic controls, aur automated setups ko mukammal protect karne ke liye Silver Steel Mills ne Custom Steel Shed Structure khud design, fabricate, aur erect kiya. Yeh heavy-duty steel roof building machinery ki operational life ko barhati hai aur workers ko un-interrupted 24/7 safe working environment faraham karti hai.

📊 Industrial Capacity & Production Matrix (SSM 24 — Khan Crete)

Year 2020 mein Peshawar mein lagaya gaya yeh machinery system Silver Steel Mills ki unmatched engineering capability aur heavy footprint ka muftakhir suboot hai. Is multi-ton automated plant ki daily production output capability ka mukammal matrix niche darj hai:

Manufactured Concrete Component	Daily Industrial Production Output Capacity	Core Engineering Utility & Application
High-Strength Interlocking Pavers	24,000 Pavers / Day	Premium housing project pathways, urban commercial pavements, and parking layouts
Standard Concrete Blocks	12,000 Blocks / Day	Commercial industrial warehouses, structural residential compounds, and high-load factory walls
Heavy-Duty Road Curbstones	4,000 Curbstones / Day	Highway margins, central road barriers, checkpoint boundaries, and modern infrastructure layouts

🛡️ Partnering with Elite Institutions & Corporate Giants for National Progress

Khan Crete Peshawar ke sath kiya gaya yeh highly integrated multi-dimensional turnkey project hamari un elite engineering collaborations ka hissa hai jo hum continuous basis par scale karte aa rahe hain. Silver Steel Mills hamesha se domestic aur international level par Frontier Works Organisation (FWO), Pakistan Army, Pakistan Air Force (PAF), aur China State Construction Engineering Corporation (CSCEC) jaise mulk ke sab se bade infrastructure, defense, aur corporate giants ke sath direct manufacturing back-end partner ke taur par kaam karne par fahr mehsoos karta hai.

Humne har complex industrial terrain, extreme climate conditions, aur rugged environments mein chalne wali highly reliable concrete engineering machinery, automated batching plants, aur pre-engineered steel buildings (PEBs) khud design aur manufacture kar ke yeh sabit kiya hai ke hum sirf machine deliver nahi karte, balkay asset-owning manufacturers ke taur par Pakistan ki qaumi tarraqi mein apna real structural infrastructure provide karte hain.

Conclusion – A Complete Factory Under One Roof

The Khan Crete project is a perfect example of why Silver Steel Mills is more than just a block machine manufacturer. We design, fabricate, and erect complete production facilities – including the steel building that protects your investment.

Whether you need a stand‑alone machine or a fully covered plant, we have the experience, the team, and the quality to deliver.
