Block Making Machine in Pakistan – High-Quality Models by Silver Steel Mills

Silver Steel Mills manufactures hydraulic concrete block making machines and complete block production plants in Pakistan for manufacturers, contractors, housing projects and industrial production facilities.

Our SSM series is designed for producing different concrete masonry and paving products by using interchangeable moulds and production configurations. Depending on the selected model and mould, the machines can be configured for hollow blocks, solid blocks, concrete pavers, interlocking tiles, tuff tiles and curb stones.

We manufacture and supply the complete production setup, including the block machine, hydraulic system, vibration system, moulds, mixers, conveyors, batching equipment and other production-line components according to the selected plant configuration.

Available SSM models:

• Silver Steel Mills manufactures a complete range of
  SSM 15 Block Making Machine,
  SSM 18 Block Making Machine,
  SSM 24 Block Making Machine,
  SSM 28 Block Making Machine,
  SSM 35 Block Making Machine
  and
  SSM 50 Block Making Machine
  for different production requirements.

For larger projects, production capacity, automation, mould configuration, batching system and material-handling equipment can be selected according to the customer’s required output.

Choose the Right Block Making Machine for Your Production

Different businesses require different production capacities. A small block manufacturer does not need the same plant configuration as a large housing scheme, infrastructure contractor or commercial paver manufacturer.

Silver Steel Mills therefore offers the SSM range in different production levels.

Important: Actual production depends on mould size, product dimensions, mix design, cycle time, curing method, operator efficiency and plant configuration. Therefore, production figures should be quoted according to the selected product rather than presenting one capacity as applicable to every mould.

SSM 15 Block Making Machine

The SSM 15 is an entry-level production machine for businesses that want to start or expand concrete block and paver manufacturing without installing a large industrial plant.

It can be configured for different moulds and products, including concrete pavers, solid blocks and other masonry products.

Typical SSM 15 configuration

• Hydraulic block-making system
• Automatic pallet/trolley arrangement according to configuration
• Heavy-duty vibration system
• Hydraulic power unit
• Interchangeable mould system
• Electrical control panel
• Concrete mixer
• Optional conveyor/batching equipment
• Custom moulds available

The SSM 15 is particularly suitable for small and medium block manufacturing businesses, contractors and local construction-material suppliers.

View SSM 15 Block Machine

SSM 18 Block Making Machine

The SSM 18 is designed for businesses requiring greater production capability than an entry-level plant.

It can be configured for concrete blocks, pavers and specialized brick production applications, including projects where fly ash or other industrial by-products form part of the approved mix design.

SSM 18 features

• Heavy-duty hydraulic system
• Industrial vibration system
• Heavy structural machine frame
• Interchangeable mould configuration
• Hydraulic power pack
• Mixer integration
• Conveyor and material-feeding options
• Production-line customization

View SSM 18 Block Machine

SSM 24 Block Making Machine

The SSM 24 is positioned for medium-to-high production operations where consistent output and reduced manual handling are important.

The plant can be configured with automatic batching, mixer, conveyor and double-layer feeding arrangements where required for premium coloured pavers and tuff tiles.

SSM 24 applications

• Concrete pavers
• Interlocking tiles
• Tuff tiles
• Solid blocks
• Hollow blocks
• Curb stones
• Other custom moulded concrete products

View SSM 24 Block Machine

SSM 28 Block Making Machine

The SSM 28 is a higher-production configuration intended for commercial manufacturers and contractors requiring greater production capacity.

Its production line can incorporate:

• Hydraulic block machine
• Double-layer feeding system
• Automatic batching
• Concrete mixer
• Conveyor belt
• Hydraulic power unit
• PLC/control system
• Interchangeable moulds

The SSM 28 is particularly suitable for large paver production, tuff tile manufacturing and commercial concrete-product plants.

SSM 28 Block Machine

SSM 35 Industrial Block & Paver Machine

The SSM 35 is designed for high-volume industrial production where the plant must continuously supply concrete products for major construction and infrastructure projects.

The system can be supplied with automated material handling, batching, mixing and conveyor equipment.

Typical applications

• Large housing schemes
• Road infrastructure
• Industrial projects
• Commercial paver manufacturing
• Large block-production yards
• Government and infrastructure contractors

View SSM 35 Block Machine

SSM 50 Heavy-Duty Block Making Plant

The SSM 50 is the high-capacity configuration in the SSM range for customers requiring large-scale concrete-product production.

It is suitable for projects where production volume, automated material handling and continuous operation are primary requirements.

The complete plant can be engineered around:

Aggregate storage → batching → mixing → conveyor feeding → hydraulic moulding → vibration → pallet handling → curing → finished-product handling

SSM 50 applications

• Mega housing developments
• Highway and infrastructure projects
• Large paver manufacturing facilities
• Industrial block production
• High-volume contractors
• Commercial construction-material suppliers

View SSM 50 Block Machine

One Block Machine – Multiple Concrete Products

One of the major advantages of a properly configured SSM production plant is its interchangeable mould capability.

Depending on the machine model and mould design, the same production platform can manufacture:

Concrete Blocks

• Hollow blocks
• Solid blocks
• 4-inch blocks
• 6-inch blocks
• 8-inch blocks
• Custom masonry sizes

Pavers & Tuff Tiles

• Interlocking pavers
• Rectangle pavers
• Zigzag pavers
• Tuff tiles
• Coloured two-layer pavers

Other Products

• Curb stones
• Kerb units
• Special concrete products
• Project-specific moulded units

Changing the mould does not mean buying another complete machine. The correct mould, feeding configuration and machine capability must be selected according to the product.

Hydraulic System – The Core of the Block Machine

Hydraulic pressure and controlled mould movement are critical to the production of dense and dimensionally consistent concrete products.

Silver Steel Mills SSM machines use a heavy-duty hydraulic power system designed around:

• Hydraulic pumps
• Hydraulic cylinders
• Oil reservoir
• Pressure-control valves
• Hydraulic hoses and fittings
• Oil filtration
• Cooling arrangements where required
• Control valves
• Hydraulic power pack

The exact pump capacity, cylinder configuration and operating pressure vary according to the SSM model.

High-Frequency Vibration System

Vibration is one of the most important parts of a concrete block machine.

During moulding, controlled vibration helps compact the semi-dry concrete mixture inside the mould and improves:

• Material distribution
• Product density
• Surface finish
• Edge definition
• Dimensional consistency

The vibration system is selected according to the machine model and mould configuration rather than using one universal specification for every product.

Concrete Mixing & Material Feeding System

A complete block production line requires consistent mixing before the material reaches the mould.

Silver Steel Mills can integrate:

Pan Mixers

Suitable for semi-dry concrete used in pavers, blocks and other precast products.

Heavy-Duty Mixers

Configured according to production volume and aggregate characteristics.

Conveyor Belts

Used for transferring:

Aggregate → Mixer → Block Machine Hopper

Automatic Batching

For larger plants, electronic weighing systems can measure aggregate quantities before mixing.

Typical materials include:

• Sand
• Crush
• Cement
• Fly ash
• Approved industrial ash
• Other suitable aggregates

The actual mix design should always be established according to the required product strength, raw-material properties and applicable project specifications.

Automatic Concrete Batching System

For commercial and industrial plants, Silver Steel Mills can supply an integrated batching system.

Production sequence

Aggregate Bins
↓
Electronic Weighing / Load Cells
↓
Conveyor
↓
Mixer
↓
Block Machine Hopper
↓
Moulding + Vibration
↓
Fresh Concrete Products
↓
Curing

Automated batching reduces manual measurement errors and helps maintain a consistent material ratio from batch to batch.

What Materials Can Be Used?

Depending on the product and approved mix design, SSM machines can process:

• Cement
• River sand
• Manufactured sand
• Crushed stone
• Stone dust
• Fly ash
• Bottom ash
• Other approved aggregates

The machine does not determine the final strength by itself. Mix design, cement content, aggregate grading, moisture control, compaction and curing all affect the finished product.

This is an important technical distinction and makes the category page more trustworthy than simply claiming that higher hydraulic pressure automatically produces higher PSI.

Block Machine Applications in Pakistan

Silver Steel Mills supplies block-making equipment for a wide range of applications:

Housing & Real Estate

Production of blocks and pavers for:

• Housing societies
• Residential developments
• Commercial buildings
• Roads
• Footpaths

Industrial Projects

• Factories
• Warehouses
• Industrial estates
• Boundary walls
• Internal roads

Infrastructure

• Highway projects
• Motorway projects
• Public infrastructure
• Drainage and road-edge works

Paver Manufacturing

Commercial paver manufacturers can produce multiple shapes and designs by changing moulds and, where required, using a double-layer feeding system.

Block Machine Manufacturer in Pakistan

Silver Steel Mills operates as a manufacturer and engineering supplier, rather than simply an equipment reseller.

Our services can include:

• Machine manufacturing
• Hydraulic system integration
• Mould manufacturing
• Mixer supply
• Conveyor systems
• Batching plants
• Electrical/control systems
• Installation
• Commissioning
• Operator training
• Spare parts
• Technical support

This allows customers to purchase a complete production solution instead of sourcing each component separately.

Block Machine Installation & Commissioning

A production plant is only useful when it is correctly installed and commissioned.

Silver Steel Mills can assist with:

1. Machine positioning
2. Hydraulic connections
3. Electrical installation
4. Motor rotation checking
5. Sensor and limit-switch adjustment
6. Mould alignment
7. Vibration adjustment
8. Mixer and conveyor commissioning
9. Trial production
10. Operator training

This is particularly important for automated plants because incorrect electrical rotation or hydraulic setup can damage equipment and cause unnecessary downtime.

Projects & Field Experience

The website’s project portfolio currently shows SSM equipment delivered for projects including SSM 35 in Karachi, SSM 24 for a Sukkur motorway project, SSM 18 for a CSCEC motorway project in Multan, fly-ash brick machinery at Nishat Power Lahore, installations in Jamshoro, Ghotki, Lahore, Gujranwala and Abbottabad, along with batching-plant projects.

These project pages are valuable for demonstrating real-world application. Keep the actual project photographs, delivery evidence and project-specific details attached to each project rather than making broad unsupported claims on the category page.

Why Choose Silver Steel Mills?

Direct Manufacturing

Buy directly from a Pakistani machinery manufacturer instead of relying entirely on an intermediary.

Multiple Machine Configurations

Choose from SSM 15, SSM 18, SSM 24, SSM 28, SSM 35 and SSM 50 according to production requirements.

Custom Moulds

Different moulds can be engineered for different block, paver, tile and curb-stone requirements.

Complete Production Lines

Machine, mixer, conveyor, batching and material-handling systems can be integrated into one production setup.

Local Technical Support

Local manufacturing and engineering support can simplify maintenance and spare-parts sourcing compared with imported equipment.

Project-Based Engineering

Production capacity, mould dimensions, automation level and material-handling configuration can be selected according to the project.

Frequently Asked Questions

What is a block making machine?

A block making machine is industrial equipment used to mould and compact semi-dry concrete mixtures into blocks, pavers, tiles, curb stones and other moulded concrete products.

Which block machine is best in Pakistan?

There is no single best model for every customer. SSM 15 and SSM 18 are suitable for smaller production requirements, while SSM 24 and SSM 28 provide higher commercial capacity. SSM 35 and SSM 50 are intended for larger industrial production.

Can one machine make both blocks and pavers?

Yes, where the selected machine configuration supports the required mould. Different products generally require different moulds and, for some paver applications, a suitable feeding/double-layer configuration.

Can SSM machines make hollow blocks?

Yes. Hollow-block moulds can be supplied according to the required block dimensions and machine model.

Can the machine produce tuff tiles?

Yes. A suitable tuff-tile/paver mould and feeding configuration can be supplied for the applicable SSM model.

Do you manufacture the moulds?

Silver Steel Mills can provide mould solutions according to the required product dimensions and machine configuration.

Is batching included with every machine?

Not necessarily. Batching, mixers, conveyors and automation are selected according to the machine model and customer’s required production-line configuration.

Can fly ash be used?

Fly ash and other industrial by-products can be used where the material is technically suitable and the mix design has been properly developed and tested for the intended product.

How much production can a block machine make?

Production depends on the machine model, mould, product size, cycle time, material feeding, operator efficiency and curing/handling system. Therefore, production should be quoted for the specific product and mould, not simply by machine name.

Do you provide installation?

Installation and commissioning support can be arranged as part of the project supply.

Get a Block Machine Quotation in Pakistan

Tell us:

• Required product: block / paver / tuff tile / curb stone
• Product dimensions
• Required daily production
• Available space
• Automation requirement
• Required moulds
• Location of installation
• Whether batching and mixer are required

Our engineering team can recommend the appropriate SSM 15, SSM 18, SSM 24, SSM 28, SSM 35 or SSM 50 configuration.

Request Technical Quotation →

Call / WhatsApp Silver Steel Mills →

Silver Steel Mills Block Machine Series

Production output depends on mould configuration, product dimensions, concrete mix design, operator skill, material availability, curing method and working hours.

SSM 15 Concrete Block & Paver Machine

The SSM 15 is designed for businesses that require a compact automatic pallet and single-trolley concrete product manufacturing system.

The documented configuration includes an aggregate storage hopper with discharge jack, movable aggregate bucket, die mould, roller conveyor, hydraulic system, vibration system, mixer, conveyor and electrical control panel.

SSM 15 Technical Specifications

• Operation: Automatic pallet and single trolley system
• Production: 100–110 pallets/hour
• Hydraulic oil capacity: 400 litres
• Moulding cycle: 25–35 seconds
• Vibration motors: 2 × 10 HP = 20 HP
• Hydraulic pump motor: 20 HP
• Mixer motor: 20 HP
• Conveyor gear motor: 3 HP
• Total connected load: approximately 63 HP
• Product height: 50–200 mm
• Pallet production: 15 rectangle pavers / pallet according to documented configuration
• Wooden pallet: 650 × 750 × 28 mm

Suitable for

• Concrete pavers
• Tuff tiles
• Concrete blocks
• Solid blocks
• Interlocking products
• Small and medium commercial production

SSM 18 Block & Brick Making Machine

The SSM 18 is a commercial single-trolley hydraulic block and paver machine designed for production of concrete blocks, bricks and tiles.

Its documented pallet configuration produces 18 tiles or 15 bricks per pallet, using 32 × 30 inch pallets.

SSM 18 Technical Specifications

• Operation: Automatic pallet and single trolley
• Production capacity: 100–110 pallets/hour
• Hydraulic oil: 410 litres
• Moulding cycle: 25–35 seconds
• Vibration: 2 × 10 HP = 20 HP
• Hydraulic pump motor: 20 HP
• Mixer motor: 20 HP
• Conveyor: 3 HP
• Total connected load: approximately 63 HP
• Belt conveyor: 30 ft
• Pallet transportation conveyor: 8 ft
• Pallet: 32 × 30 inches
• Products per pallet: 18 tiles or 15 bricks

The machine specification also includes a hydraulic cooling system, 220-bar three-ply hydraulic pipes and imported hydraulic components.

SSM 24 Double-Layer Tuff Tile & Paver Plant

The SSM 24 is designed as a higher-capacity double-layer concrete product plant for commercial production of pavers, tuff tiles and concrete products.

The documented plant configuration includes:

• Complete double-layer block/paver/tuff tile plant
• 30 HP hydraulic power unit
• Hydraulic operating assembly
• Electrical control panel
• Vibration foundation table
• 2-bag concrete mixer
• 30 HP mixer motor
• 1-bag colour mixer
• 10 HP colour mixer motor
• Colour topping conveyor
• Concrete conveyor
• Aggregate storage hopper
• Colour topping hopper
• Movable aggregate bucket
• Movable colour bucket
• 20-ft pallet chain conveyor

SSM 24 Power Configuration

• Hydraulic pump: 30 HP
• Vibration motors: 2 × 20 HP = 40 HP
• Mixer motors: 30 + 10 HP = 40 HP
• Stacker/conveyors: 15 HP
• Batching hopper conveyor: 10 HP
• Total documented connected load: approximately 135 HP
• Hydraulic oil requirement: 600 litres

The documented SSM 24 specification states that product strength can vary according to product dimensions and concrete recipe, with the plant configuration capable of producing products in the 1,000–7,000 PSI range under appropriate mix and production conditions.

SSM 28 Automatic Block & Paver Machine With Batching

The SSM 28 combines concrete product manufacturing with an optional digital batching system.

Its batching configuration includes:

• 3 aggregate storage hoppers
• Digital weighing/load-cell system
• Movable aggregate bucket
• Pigment/material feeding system
• Conveyor system
• 30-ft conveyor
• Air compressor
• Automatic pallet system
• Wooden pallets
• Single-trolley machine configuration

SSM 28 Technical Specifications

• Operation: Automatic pallet and single trolley
• Hydraulic oil: 500 litres
• Vibration motors: 2 × 15 HP = 30 HP
• Hydraulic pump: 25 HP
• Mixer: 30 HP
• Stacker + conveyors: 10 HP
• Batching hopper system: 10 HP
• Total connected load: approximately 105 HP
• Product height: 50–200 mm
• Pallet: 35 × 42 according to quotation documentation
• Production configuration: 28 rectangle pavers/pallet

Automatic Batching for Consistent Concrete Production

The SSM 28 batching configuration uses multiple material hoppers and digital weighing/load-cell components to control aggregate feeding before mixing.

This allows the operator to control the quantity of:

• Sand
• Crush
• Cement
• Fly ash
• Other approved aggregate materials

according to the required concrete mix design.

SSM 35 Heavy-Duty Block & Paver Plant

The SSM 35 is designed for higher-volume commercial and industrial concrete product production.

The documented system uses an automatic pallet and double-trolley arrangement with integrated vibration, hydraulic power, mixers, conveyors and stacker.

SSM 35 Technical Specifications

• Operation: Automatic pallet + double trolley
• Production capacity: 80–100 pallets/hour
• Hydraulic oil: 800 litres
• Moulding cycle: 20–30 seconds
• Vibration motors: 2 × 20 HP = 40 HP
• Hydraulic pump motor: 30 HP
• Mixer motors: 10 + 30 kW configuration = approximately 40 HP
• Conveyors: approximately 11 HP
• Stacker: approximately 10 HP
• Total connected load: approximately 131 HP
• Product height: 50–200 mm
• Rectangle pavers: 35 per pallet in the documented configuration
• Brick production: documented output of approximately 24,000 bricks/day for the specified 6 × 8 × 12-inch product
• Wooden pallet: 889 × 1219 × 38 mm

Actual daily production varies according to mould size, product configuration, operator experience, labour efficiency, electricity supply and raw-material availability.

SSM D50 High-Capacity Block & Paver Plant

The SSM D50 is Silver Steel Mills’ high-capacity production configuration for large-scale concrete paver and brick manufacturing.

SSM D50 Technical Specifications

• Operation: Automatic pallet and double trolley
• Production capacity: 80–100 pallets/hour
• Hydraulic oil: 800 litres
• Moulding cycle: 20–30 seconds
• Vibration motors: 2 × 30 HP = 60 HP
• Hydraulic pump motor: 40 HP
• Mixer motors: approximately 40 HP
• Conveyors: approximately 11 HP
• Stacker: approximately 10 HP
• Total connected load: approximately 161 HP
• Product height: 50–200 mm
• Rectangle paver configuration: 50 products/pallet
• Documented paver output: approximately 40,000 rectangle pavers/day
• Brick configuration: 36 bricks/pallet
• Documented brick output: approximately 36,000 bricks/day
• Wooden pallet: 1219 × 1219 × 38 mm

This model is intended for large production yards, housing developments, contractors, infrastructure projects and commercial block/paver manufacturing operations.

What Can Silver Steel Mills Block Machines Produce?

Silver Steel Mills machines can be configured with interchangeable moulds for different concrete products, subject to machine model and mould configuration.

Concrete Blocks

• Hollow concrete blocks
• Solid concrete blocks
• Masonry blocks
• Construction blocks
• Concrete bricks

Paving Products

• Interlocking pavers
• Rectangle pavers
• Tuff tiles
• Decorative concrete tiles
• Coloured pavers
• Double-layer pavers

Other Concrete Products

• Curb stones
• Kerb stones
• Special-size concrete products
• Custom mould products

Moulds are selected according to the required product dimensions, thickness, shape and production capacity.

Hydraulic Compaction & Vibration System

The core of a concrete block machine is the combination of hydraulic compaction and controlled vibration.

Silver Steel Mills machines use heavy-duty vibration systems together with hydraulic pressing to compact the semi-dry concrete mixture inside the mould.

This process helps achieve:

• Better material compaction
• Consistent product geometry
• Reduced internal voids
• Uniform mould filling
• Improved production consistency

The actual compressive strength of the finished product depends on the cement content, aggregate grading, water-cement ratio, product dimensions, curing conditions, vibration and compaction settings.

Heavy-Duty Moulds

Silver Steel Mills supplies interchangeable mould configurations according to the machine and required product.

Mould construction can include:

• Heavy MS plate
• Q235/Q235B steel components
• CNC-machined surfaces
• Hard flat bars
• Precision-machined punch components
• Custom product cavities

The SSM 18 documentation, for example, specifies Q235B MS imported hard flat bar and CNC machining/engraving for the mould and top punch.

Concrete Mixers for Block Machine Plants

A block machine cannot produce consistent products without proper concrete mixing.

Silver Steel Mills integrates heavy-duty mixers according to the plant configuration.

Available configurations include:

• Concrete drum mixers
• Heavy-duty concrete mixers
• Colour topping mixers
• Pan mixer configurations
• Special mixers for fly ash and biomass ash applications

For example, the SSM 24 configuration includes a 2-bag concrete mixer with a 30 HP motor and a separate 1-bag colour mixer with a 10 HP motor.

Conveyor Systems & Material Handling

Silver Steel Mills block plants can incorporate multiple conveyor systems for automated material movement.

These include:

• Aggregate conveyors
• Concrete conveyors
• Colour topping conveyors
• Pallet chain conveyors
• Stacker conveyors
• Material transfer belts
• Movable aggregate buckets

The SSM 18 documentation, for example, specifies a heavy-duty material conveyor and separate gearboxes for the mixer and belt conveyor.

Automatic Concrete Batching System

For customers requiring higher process control, Silver Steel Mills provides automatic concrete batching systems integrated with selected block and paver plants.

The batching system can include:

• Aggregate storage hoppers
• Digital weighing
• Load cells
• Material discharge gates
• Movable buckets
• Conveyors
• Control system
• Cement and aggregate feeding arrangements

The objective is to maintain a repeatable material ratio from batch to batch.

Block Machine Applications

Silver Steel Mills concrete block machines are suitable for:

• Block manufacturing factories
• Paver manufacturing plants
• Tuff tile factories
• Housing projects
• Housing societies
• Road construction contractors
• Building material suppliers
• Infrastructure contractors
• Commercial concrete-product yards
• Industrial construction projects
• Fly ash and alternative-material production applications

Which SSM Block Machine Should You Choose?

Choose SSM 15 if:

You need a compact production machine with relatively lower connected power and a single-trolley automatic pallet system.

Choose SSM 18 if:

You need a commercial single-trolley machine for bricks, tiles and pavers.

Choose SSM 24 if:

You require a double-layer tuff tile/paver production plant with colour topping and batching integration.

Choose SSM 28 if:

You need an automatic pallet system combined with digital aggregate batching.

Choose SSM 35 if:

You need a higher-volume double-trolley industrial production plant.

Choose SSM D50 if:

Your business requires a large-scale paver and brick manufacturing operation with high production targets.

Complete Block Machine Plant From One Manufacturer

Silver Steel Mills can provide more than the main hydraulic block machine.

Depending on the selected configuration, a complete plant can include:

Block Machine → Hydraulic System → Vibration System → Mixer → Aggregate Hopper → Batching System → Conveyors → Stacker → Wooden Pallets → Moulds → Electrical Control System

This allows customers to purchase a coordinated production system rather than assembling unrelated machinery from different suppliers.

Block Machine Manufacturing in Pakistan

Silver Steel Mills manufactures concrete block and paver machinery in Pakistan for customers requiring locally supported industrial equipment.

Our machinery portfolio includes:

Concrete Block Machines
Paver Machines
Tuff Tile Machines
Automatic Block Plants
Semi-Automatic Block Machines
Fly Ash Brick Machines
Batching Systems
Concrete Mixers
Material Conveyors
Pallet Stackers
Concrete Product Moulds

We provide machine configurations according to production requirement, product type, available space, electrical capacity and budget.

Why Choose Silver Steel Mills?

Direct Manufacturer

Silver Steel Mills manufactures and assembles industrial machinery in Pakistan rather than operating only as a machinery trading company.

Multiple Production Models

Customers can select from SSM 15, SSM 18, SSM 24, SSM 28, SSM 35 and SSM D50 configurations.

Custom Moulds

Different block, brick, paver, tile and curb-stone moulds can be supplied according to machine compatibility.

Complete Production Lines

Machines can be combined with mixers, conveyors, batching systems, pallet systems and stackers.

Local Technical Support

Installation, commissioning and technical assistance are available according to the selected machine and project arrangement.

Factory-Direct Supply

Customers can discuss their production requirement directly with the manufacturer and receive a machine configuration rather than selecting only from a generic imported catalogue.

Block Machine Quotation & Technical Specifications

Looking for the block machine price in Pakistan, complete plant quotation, electrical load, mould configuration, production capacity or installation details?

Silver Steel Mills can prepare a technical quotation according to:

• Required daily production
• Block size
• Paver size
• Tuff tile thickness
• Number of moulds
• Automatic or semi-automatic operation
• Batching requirement
• Available electricity
• Available production area
• Required pallet system
• Budget

Request the technical quotation before selecting your machine so the production capacity and mould configuration match your actual business requirement.

Frequently Asked Questions

What is the best block making machine in Pakistan?

The best machine depends on required production, product type, available electricity, space and budget. Silver Steel Mills offers several SSM configurations from SSM 15 through high-capacity SSM D50.

What products can a block machine make?

Depending on the mould and machine configuration, the plant can manufacture concrete blocks, solid blocks, pavers, tuff tiles, bricks and curb stones.

Can the machine make different sizes of blocks?

Yes. Interchangeable moulds can be supplied for different product dimensions, subject to the machine’s mould compatibility and maximum product height.

Do you provide batching plants with block machines?

Yes. Selected SSM models can be supplied with integrated aggregate batching and digital weighing systems.

Do you provide mixers and conveyors?

Yes. Complete plant configurations can include concrete mixers, colour mixers, material conveyors, pallet conveyors and stackers.

Is installation available?

Silver Steel Mills provides technician/installation and commissioning arrangements according to the quotation and project requirements. The uploaded quotations specify technician assistance for erection and commissioning, while site utilities, foundation and certain installation requirements are the buyer’s responsibility.

A block making machine is a complex assembly of hydraulic systems, electric motors, sensors, and a central controller. Incorrect wiring can lead to:

• Motor damage (burning out due to reverse rotation)

• Hydraulic system failure (pressure losses, leaks)

• Sensor misreading (incorrect mould position, material flow errors)

• Production downtime (costing you thousands of rupees per hour)

At Silver Steel Mills, we don’t just manufacture SSM series block machines (SSM 15, 18, 24, 35, 50). We also provide complete on‑site installation, wiring, and training to ensure your plant operates at peak efficiency.

This technical guide is based on our actual field installation procedures – the same steps our engineers follow when setting up machines for clients like Nishat Power, CSCEC (CPEC Motorway), DHA Multan, and Gulberg Greens Islamabad.

⚠️ Safety Warning: Electrical and hydraulic work should only be performed by trained professionals. The following guide is for reference and training purposes. Always isolate power before handling wires.

Part 1: Understanding Your Block Machine’s Key Components

Before connecting any wires, identify the main components of your SSM block machine:

Our SSM machines have four primary electric motors:

1. Two vibration motors (under the mould box) – generate high‑frequency vibration.

2. One material feeding motor (agitator) – pushes mix into the mould.

3. One conveyor / feeder motor – moves raw material from hopper to mould.

Plus a hydraulic pump motor (located on the hydraulic tank).

Part 2: Hydraulic System Connections – Direction Matters

2.1 Identifying Hydraulic Hoses

The hydraulic system has two main hoses connecting the power pack to the main cylinder:

Critical Rule: The wider (larger diameter) hose goes to the right side of the cylinder. The narrower hose goes to the left side. Reversing these will prevent the mould from lifting or pressing properly.

2.2 Checking Hydraulic Oil Level

Before first start, fill the hydraulic tank with 800 litres (for SSM 35) or 400 litres (for SSM 15/18) of ISO VG 46 or 68 hydraulic oil. Use a dipstick or sight glass to verify level. Low oil causes cavitation and pump damage.

2.3 Tightening Fittings

After connecting hoses, use a torque wrench to tighten all fittings to 20‑25 Nm (for 1/2″ BSP). Do not over‑tighten – you may crack the fitting.

Part 3: Wiring the Electric Motors – Step by Step

All SSM machines use 3‑phase, 380‑415V AC motors. Each motor has a terminal box with three wires (usually red, yellow, green – or U, V, W). The controller box has corresponding output terminals (labelled M1, M2, M3, etc.).

3.1 Identifying the Four Motors

On a typical SSM block machine:

Additionally, the hydraulic pump motor (labelled M5 or P) is on the hydraulic tank.

3.2 Connecting Wires

1. Run cables from each motor to the controller box. Use flexible, oil‑resistant cable (4‑core, 4‑6 mm²).

2. Match wire colours – connect each motor’s three wires to the corresponding terminals in the controller box (e.g., M1‑1, M1‑2, M1‑3).

3. Secure the connections with cable lugs and tighten screws.

Important: Do not worry about direction yet. We will test and reverse any motor that spins incorrectly.

3.3 Testing Motor Rotation Direction

After all wires are connected, power on the machine and briefly jog each motor (press start for 1 second, then stop).

For Vibration Motors (M1 and M2):

• Correct: The two motors must rotate in opposite directions (one clockwise, the other counter‑clockwise). This creates a balanced, high‑amplitude vibration.

• Incorrect: If both rotate the same direction, the mould will shake sideways and damage the machine.

For the Material Feeding Motor (M3):

• Correct: Rotates such that the agitator pushes material towards the mould cavity.

• Incorrect: Material moves away – production stops.

For the Conveyor Motor (M4):

• Correct: Belt moves towards the mould hopper.

• Incorrect: Belt moves backwards, material spills.

For the Hydraulic Pump Motor (M5):

• Correct: Pump rotates clockwise (when viewed from the fan end). Check the arrow on the pump housing.

• Incorrect: Pump runs dry – can seize within minutes.

3.4 Changing Rotation Direction

To reverse a 3‑phase motor, swap any two of the three wires at the motor terminal box or the controller output. For example, if the motor has wires U, V, W connected to terminals 1, 2, 3, swap V and W (connect U→1, W→2, V→3).

Repeat the test until all motors rotate correctly.

Part 4: Sensor Connections – Limit Switches and Proximity Sensors

Your SSM block machine uses inductive proximity sensors (or micro switches) to detect:

• Mould top position (when the mould box lifts fully)

• Mould bottom position (after pressing)

• Material cut front/back position (feeder movement)

• Pallet feeder position (for automatic stacking)

Each sensor has three wires:

4.1 Identifying Sensor Locations and Inputs

From our field installation notes (based on the video transcript):

Pro tip: Write these labels on masking tape and stick them next to each sensor for easy maintenance.

4.2 Wiring Procedure

1. Connect the black wire of each sensor to its assigned X input (e.g., mould top limit black wire to X0).

2. Connect all brown wires from all sensors together, then connect to the V+ (24V supply) terminal in the controller box.

3. Connect all blue wires from all sensors together, then connect to the V‑ (common / ground) terminal.

4.3 Testing Sensors

After wiring, power on the controller and manually trigger each sensor (e.g., move the mould up by hand until the limit switch clicks). The corresponding input LED on the PLC or controller should light up. If not:

• Check the black wire connection.

• Verify 24V supply between brown and blue (use a multimeter).

• Replace the sensor if defective.

Part 5: Controller Box – Final Integration and Cover Installation

The controller box houses the PLC (or digital board), relays, and terminal strips. After all hydraulic hoses, motor cables, and sensor wires are connected:

1. Organize wires using cable ties – keep low‑voltage (sensor) wires away from high‑voltage (motor) wires to prevent interference.

2. Close the controller box cover securely to protect against dust and moisture.

3. Label the outside with the machine model (SSM 15/18/24/35/50) and date of installation.

Part 6: First Test Run – What to Check

Before full production, run a dry cycle (without concrete mix):

1. Start hydraulic pump – listen for unusual noise (knocking indicates air in the system – bleed it).

2. Jog each motor again to confirm direction.

3. Perform a full automatic cycle using the keyboard/PLC:

   • Feeder forward → material drop → vibration → hydraulic press → mould lift → feeder return → pallet advance.

4. Observe sensors – the cycle should stop immediately if a limit is reached.

If any step fails, double‑check the corresponding sensor or motor wiring.

Silver Steel Mills – Your Partner Beyond the Machine

Installing and wiring a block making machine is a technical task that requires experience. Silver Steel Mills offers:

• On‑site commissioning – our engineers travel to your location anywhere in Pakistan.

• Operator training – 2‑week hands‑on training for your staff, including wiring basics, troubleshooting, and maintenance.

• After‑sales support – 3 months free service, with spare parts (sensors, cables, hydraulic seals) available from our Gujranwala factory.

• Remote phone support – call us if you face any electrical or hydraulic issue.

“When we installed the SSM 18 for CSCEC on the CPEC motorway, our team spent a full day wiring and testing the entire plant. The CSCEC engineers later told us that our wiring diagram was the most detailed they had ever seen.” – Silver Steel Mills Senior Technician

Frequently Asked Questions (FAQ) – Wiring & Installation

Q1: Can I use any electric cable for the motors?

A: Use 4‑core, 4‑6 mm² copper flexible cable (PVC insulated, oil‑resistant). Avoid aluminium wires – they overheat.

Q2: What happens if I reverse the two vibration motors?

A: They will both spin the same direction, cancelling out vibration. The blocks will be weak and uneven. Immediately swap two wires on one motor.

Q3: How do I know if a proximity sensor is working?

A: Bring a metal object (like a screwdriver) close to the sensor face. The LED on the sensor should light up, and the corresponding input on the controller should turn ON.

Q4: The hydraulic pump makes a loud grinding noise. Why?

A: Air in the system. Check oil level – it may be low. Run the pump for 5‑10 minutes with the pressure valve open to bleed air.

Q5: My mould won’t lift after pressing. Which sensor should I check?

A: The mould bottom limit (X1). If this sensor stays active, the PLC thinks the mould is already down and won’t lift. Clean or replace the sensor.

Conclusion – Master Your Block Machine with Silver Steel Mills

Proper wiring of the hydraulic system, motors, and sensors is essential for safe, efficient block production. This guide gives you the knowledge to install and troubleshoot your SSM series block machine. However, for best results, we always recommend having our certified technicians handle the initial installation and training.

Silver Steel Mills – Pakistan’s leading manufacturer of SSM block machines (15, 18, 24, 35, 50) for fly ash bricks, pavers, hollow blocks, and curbstones. From Nishat Power to CPEC motorway, from DHA Multan to Gulberg Greens, our machines are trusted by industry leaders.

1. What Can a Block Making Machine Produce?

Modern automated block machines are highly versatile. By switching the heavy-duty die moulds, a single machine can manufacture a diverse array of structural and decorative products:

• Fly Ash Bricks: Utilizing industrial waste (fly ash or biomass ash) mixed with sand, lime, or cement to construct high-density, perfectly uniform building bricks.

• Hollow Blocks: Commonly utilized in commercial and boundary walls, these units provide excellent thermal and acoustic insulation while reducing structure dead weight.

• Solid Concrete Blocks: Heavy-load-bearing masonry units crucial for structural foundations and load-bearing walls.

• Tuff Tiles / Interlocking Pavers: High-PSI pavers (ranging from 6,000 to 7,000+ PSI) available in rectangular, zig-zag, or hexagonal configurations, used extensively for streets, gas stations, and parking lots.

• Kerbstones / Curbstones: Solid, elongated perimeter blocks used globally to delineate road shoulders, footpaths, and highway medians.

2. Essential Raw Materials and the Production Recipe

To produce premium, commercial-grade bricks and blocks that satisfy international engineering standards, specific raw material blending is essential:

1. Fly Ash / Biomass Ash: Acting as a sustainable pozzolanic binder, fly ash reacts chemically with calcium hydroxide to elevate the long-term durability of the unit.

2. Sand: Finely graded river sand or pit sand functions as a vital structural aggregate filler.

3. Crush / Aggregate Dust (0mm to 5mm): Fine crushed stone dust or small aggregate chips provide structural strength and concrete density.

4. Portland Cement: Functions as the primary chemical adhesive binder holding the aggregate formulation together.

5. Water: Regulated carefully during digital batching to trigger cement hydration without making the mix overly wet.

3. Engineering Specifications of Silver Steel Mills Machinery

Silver Steel Mills (SSM) manufactures an extensive portfolio of concrete block-making plants in Pakistan, ranging from entry-level single-trolley machines to massive automated batching industrial plants. Below is an extensive technical breakdown of their flagship commercial models:

Model 1: SSM 15 Single Portion Plant

Designed for small-to-medium enterprises entering the block manufacturing business.

• System Configuration: Auto pallet with a single-trolley delivery design.

• Production Velocity: Outputs 100 to 110 pallets per hour.

• Pallet Capacity: Accommodates 15 rectangular pavers or 6 standard blocks per cycle.

• Molding Cycle Duration: 25 to 35 seconds per compression stroke.

• Electrical Power Load: 63 HP total capacity usage (including 20 HP vibration, 20 HP hydraulic pump, and 20 HP mixer machine motors).

• Pallet Footprint: Uses 650mm × 750mm × 28mm wooden pallets.

Model 2: SSM 18 Brick Unified Plant

Optimized specifically for high-volume biomass and industrial fly ash brick projects.

• System Configuration: Single portion platform engineered with premium SS400 chrome shafts and heavy-duty Q235 MS imported sheet steel structures.

• Hydraulic Pumping Force: Outfitted with an extraordinary 21-gallon dual pump delivering up to 10,000 PSI of working pressure along with an integrated hydraulic oil cooling radiator system.

• Pallet Capacity: Holds 18 interlocking tiles or 15 high-density bricks per compression cycle.

• Raw Material Storage: Outfitted with a special extra-large aggregate storage hopper with a chrome-shafted hydraulic discharging door.

• Material Conveyance: Features a 30-foot heavy-duty aggregate belt conveyor paired with an 8-foot automated pallet transport chain conveyor driven by a 3 HP gear motor.

Model 3: SSM 24 Double Layer Plant with Batching System

An advanced choice for producing dual-layer premium tuff tiles with a top colored pigment finish.

• System Configuration: Fully automatic double-layer plant incorporating dedicated aggregate and pigment hoppers.

• Electrical Power Load: Consumes 135 HP total capacity usage (30 HP hydraulic pump, 40 HP dual vibration motors, 40 HP combined mixer drives, and 15 HP stacker/conveyor systems).

• Hydraulic Capacity: Requires a 600-liter hydraulic oil reservoir complemented by 50 liters of industrial gear oil.

• Pallet Footprint: Utilizes a 30″ × 42″ heavy wooden pallet configuration.

Model 4: SSM 35 Fully Automatic Batching Plant

A premium high-output industrial system utilizing automated digital batching networks.

• System Configuration: Auto pallet paired with an efficient double-trolley delivery matrix.

• Production Velocity: Alternates between 80 to 100 pallets per operational hour.

• Pallet Capacity: Compresses 35 rectangular paver units per stroke.

• Daily Structural Output: Capable of generating up to 24,000 premium bricks or blocks in a single standard shift.

• Electrical Power Load: Operates on a 131 HP power grid layout (40 HP vibration, 30 HP hydraulic, 40 HP mixer, 11 HP conveyor, and 10 HP automated stacker systems).

• Molding Cycle Duration: Fast cycle times ranging from 20 to 30 seconds.

Model 5: SSM 50 Industrial block making machine

The highest-capacity production system manufactured by SSM for mega infrastructure projects.

• System Configuration: Premium double-trolley automated layout utilizing full digital batching, weighing scales, and PLC touch panels.

• Production Velocity: Sustains 80 to 100 large-format pallets hourly.

• Pallet Capacity: Accommodates 50 rectangular pavers or 36 metric standard bricks (dimensions: 228mm × 110mm × 76mm) per compression cycle.

• Daily Structural Output: Easily delivers an impressive 40,000 interlocking pavers or bricks per shift.

• Electrical Power Load: Engineered for a 161 HP industrial load, backed by heavy-duty 60 HP dual-vibration motors and a 40 HP hydraulic pump system.

• Hydraulic Capacity: Requires an 800-liter hydraulic oil reservoir to manage heavy continuous production cycles.

4. The Plant Site Layout and Workflow Blueprint

Setting up a professional concrete block plant requires strategic spatial planning. Below is an architectural blueprint demonstrating how raw materials transition into finished, cured products:

[ Raw Material Storage ] -------> [ Digital Batching Plant ]
 (Sand, Crush, Fly Ash)             (Weighs Materials Accurately)
                                                |
                                                v
[ Finished Product Stacking ] <--- [ Hydraulic Compression ] <--- [ Twin Shaft Mixer ]
 (Curing Yards & Shipping)          (Moulds & Shakes Blocks)       (Water & Cement Mix)

1. The Feeding Zone: Front-end wheel loaders dump sand, crush stone, and fly ash into individual compartments of the digital aggregate batching plant.

2. The Mixing Zone: The automated batching system weighs the ingredients precisely before discharging them into a high-intensity twin-shaft mixer, where cement and water are added.

3. The Molding Zone: The wet concrete mix travels via an overhead conveyor belt into the machine’s primary storage hopper. It fills the precision CNC-engraved steel die mould.

4. The Compression Stage: A combination of intense hydraulic downward pressure (up to 10,000 PSI) and vertical table vibration compacts the mix, solidifying it into blocks within seconds.

5. The Stacking & Curing Stage: The automated pallet stacker lifts and organizes the fresh wet blocks. Forklifts or loaders then transport them to a dedicated curing yard, where they are misted with water for 7 to 14 days to reach peak structural strength.

5. Cost-Benefit Analysis: Why Investing in Automatic Block Machines is Highly Lucrative

Shifting from primitive brick kilns to high-tech automated block production offers compelling financial returns.

Faster Payback Periods

According to industry feasibility studies for mid-tier machinery like the SSM 35, a well-managed plant can produce substantial monthly returns. For example, a factory operating at standard capacity can generate substantial monthly revenue, yielding an average capital payback period of just 15 months. This makes it one of the most secure and fast-recovering investments in Pakistan’s industrial manufacturing sector.

Significant Environmental Compliance

Traditional brick kilns are frequently shut down by Environmental Protection Departments due to their reliance on coal and rubber combustion, which releases toxic black carbon smoke. In contrast, block-making machines use clean, hydraulic electricity, emit zero smoke, and actively repurpose industrial waste like fly ash—making them completely immune to environmental closures.

Superior Technical Advantages

• Impeccable Structural Integrity: Machine-pressed units resist water absorption far better than clay bricks, preventing structural issues like saltpetre (shora) damage on plaster walls.

• Perfect Dimensional Accuracy: Standardized machine blocks eliminate structural irregularities, cutting down masonry mortar consumption by up to 30%.

• Reduced Labor Dependency: Fully automatic plants handle heavy-duty processes like aggregate batching and pallet stacking mechanically, lowering manual labor requirements and reducing human error.

Traditional clay bricks suffer from major dimensional variations, seasonal production halts due to winter smog, and high water absorption, which triggers structural damage (shora). Modern contractors and developers have shifted their focus completely toward automated concrete block making machines.

By processing locally available raw materials—including river sand, crushed stone aggregate, cement, and industrial waste like fly ash or biomass ash—these heavy-duty machines compress and vibrate high-density solid blocks, hollow insulation blocks, interlocking tuff tiles/pavers (capable of reaching 6,000 to 7,000+ PSI), and road curbstones with absolute geometric precision.

As the country’s premier engineering house for construction machinery, Silver Steel Mills (SSM) designs, fabricates, and installs fully integrated concrete brick and paver lines. Below is a detailed technical analysis of the official SSM industrial machinery lineup, based directly on certified factory blueprints and feasibility specifications.

Building the CPEC Backbone: A Story of Engineering Resilience

The CPEC (China-Pakistan Economic Corridor) is more than just a network of roads; it is the lifeline of Pakistan’s future infrastructure. Among the most challenging sections of this massive undertaking was the Multan-Sukkur Motorway (M-5). While the asphalt and bridges are often the focus, the silent heroes of this project are the millions of concrete blocks, tuff tiles, and kerbstones that line the interchanges, rest areas, and drainage systems of this high-speed arterial route.

This is a story of how an engineering crisis nearly halted a national mega-project, and how a local Pakistani manufacturer turned that crisis into a triumph of home-grown engineering.

The Crisis: When High-Tech Fails

When the China State Construction Engineering Corporation (CSCEC)—a global titan in construction—first arrived at the M-5 site, they came prepared. They imported high-tech, multi-million dollar machinery directly from China, expecting a seamless manufacturing process for the massive quantities of blocks and pavers required.

However, the reality of the construction site didn’t match the climate-controlled environment of a factory. The imported machinery struggled with local environmental factors, moisture levels in the sand, and the specific composition of local aggregates. Technical breakdowns became a daily occurrence. The “high-tech” systems were stalling, the production line was silent, and the clock on the Multan-Sukkur project was ticking.

The project was at risk of a major delay. The Chinese engineers were frustrated, and the dream of a seamless motorway handover felt like it was slipping away.

The Turning Point: Entering Silver Steel Mills (SSM)

In the middle of the frustration, the CSCEC leadership decided to look for a local solution. They reached out to Silver Steel Mills (SSM).

When our engineering team first arrived at the Jalalpur Pirwala, Hyderabad, and Sukkur units, we didn’t just see broken machines; we saw an engineering challenge. We analyzed why the imported plants were failing. It wasn’t about the power of the motors; it was about adaptation. The machines weren’t designed to handle the specific raw material variations of Pakistan’s soil and fly ash waste.

Our team went back to the drawing board. We didn’t just repair the old machines; we designed a specialized, custom-engineered block-making solution from the ground up, specifically for the harsh conditions of the CPEC site.

The Solution: Precision Built for Pakistan

We fabricated machines that were not just “industrial”—they were resilient. We implemented robust hydraulic systems, high-frequency vibration tables, and custom die moulds that could handle the local fly ash and concrete mix with precision.

The installation was a race against time. From Jalalpur Pirwala to Sukkur, our technicians worked side-by-side with the CSCEC team, commissioning the plants under the intense heat of the Pakistani summer.

The moment the first pallet of high-density tuff tiles rolled off the SSM-designed machine, the atmosphere changed. The blocks were perfect—consistent in size, high in compressive strength, and durable enough to withstand the load of heavy motor traffic for decades.

The Result: A Motorway Built on Reliability

The difference in production was night and day. The SSM machines ran continuously, hitting the targets that the imported machines couldn’t touch. We produced millions of blocks, pavers, and kerbstones that now define the M-5 motorway.

The Chinese engineers, initially skeptical of local solutions, were genuinely impressed. They were accustomed to global technology, but they hadn’t seen engineering that was so perfectly tailored to the project’s unique operational needs. They saw that the real secret to CPEC’s success wasn’t just bringing technology from abroad—it was localizing that technology to work in our backyard.

The Multan-Sukkur Motorway was completed on time. The client was delighted. For the team at Silver Steel Mills, that project was more than just a contract; it was the moment we proved that Pakistani engineering could stand toe-to-toe with the best in the world.

Lessons Learned: Why Local Expertise Matters

The success of the M-5 project taught us a valuable lesson: Construction machinery isn’t just about high-speed motors; it’s about compatibility with the site.

Today, Silver Steel Mills continues to supply plants to every corner of Pakistan—from Lahore and Faisalabad to Peshawar and Karachi. We use the same grit and engineering expertise that we brought to the CPEC project to empower local contractors and businessmen.

Whether you are building a small housing society or a massive national highway, the lesson remains the same: If you have a manufacturing problem, you need a local partner who understands the terrain.

Are you ready to build the future? At Silver Steel Mills, we don’t just sell machines; we provide the backbone for your construction dreams. Let us help you design your next production line with the same precision that built the backbone of CPEC.

Pakistan’s construction sector is expanding at a breakneck pace. From massive infrastructure ventures like CPEC highways and public transport corridors to high-rise commercial sectors and housing schemes, the demand for resilient building units is at an all-time high. Traditionally, old-school red clay brick kilns (bhatta) dominated the local market. However, due to severe environmental lockdowns over heavy smog, seasonal operational halts, and inconsistent quality, a massive structural shift toward automated block making machines is underway.

Modern machinery manufactures high-strength concrete elements efficiently using eco-friendly raw materials. Prominent local manufacturers, such as Silver Steel Mills (SSM), lead this industrial movement by providing heavy-duty, fully automatic concrete block and paver plants engineered tailored to Pakistan’s demanding conditions.

The Raw Material Recipe & Product Blueprint

To achieve premium, load-bearing quality that complies with international building codes, the automatic block machine utilizes a synchronized aggregate matrix:

1. Industrial Fly Ash / Biomass Ash: Acts as a highly reactive pozzolanic binder that improves the structural density, water resistance, and long-term lifespan of grey bricks.

2. Crushed Aggregate Dust (0mm to 5mm): Provides the structural bedrock and extreme interlocking mass required to reach high compressive strength thresholds.

3. River Sand: Acts as a fine aggregate filler to fill micro-voids, ensuring smooth product surfaces and sharp edges.

4. Portland Cement: The chemical adhesive that activates upon controlled moisture contact to secure the entire aggregate blend.

Official Silver Steel Mills (SSM) Machine Specifications

1. SSM 15 Auto block making machine

An excellent entry-level solution designed for small-to-medium enterprises (SMEs), housing schemes, and localized masonry startups looking for a low capital layout.

• Machine Operation System: Auto pallet and single-trolley delivery system.

• Production Capacity: 100 to 110 pallets per hour.

• Molding Cycle Speed: 25 to 35 seconds per compression stroke.

• Pallet Product Capacity: Holds 15 Rectangular Pavers or 6 Standard Blocks per single pallet drop.

• Wooden Pallet Dimensions: 650mm × 750mm × 28mm.

• Supported Product Height: Flexible molding depth between 50mm to 200mm.

• Total Electrical Power Grid Load: 63 HP

  • Vibration Motors: 20 HP ($10\text{ HP} \times 2$)

  • Hydraulic Pump Motor: 20 HP

  • Mixer Machine Motor: 20 HP

  • Conveyor Gear Motor: 3 HP

2. SSM 18 Brick Unified Plant (Biomass & Fly Ash Focus)

Specially engineered to handle the abrasive nature and volumetric demands of biomass ash and industrial fly ash material recipes.

• Structural Composition: Manufactured using premium SS400 steel framing, solid SS chrome shafts, and Q235 MS imported sheet steel cores to resist continuous mechanical stress.

• Extreme Hydraulic Compaction: Outfitted with an extraordinary 21-gallon dual pump assembly generating up to 10,000 PSI of crushing working pressure, backed by an integrated hydraulic oil cooling radiator system.

• Die Mould Technology: Q235B high-grade imported hard flat bar steel shaped via precise CNC machining and top-punch engraving.

• Pallet Product Capacity: Delivers 18 Interlocking Tiles or 15 High-Density Bricks per pallet drop.

• Wooden Pallet Dimensions: 32 inches × 30 inches.

• Material Conveyance Setup: Features an elongated 30-foot heavy-duty aggregate belt conveyor and an 8-foot automatic chain transport conveyor driven by a 3 HP gear motor.

• Total Electrical Power Grid Load: 63 HP (Balanced across a 20 HP hydraulic pump, 20 HP high-amplitude vibrators, and a 20 HP compulsory mixer).

3. SSM 24 Double-Layer Plant (With Batching System)

The industrial standard for manufacturing premium, dual-layer interlocking tuff tiles with a vibrant, high-wear colored pigment top-coat.

• Machine Operation System: Fully automatic, double-layer design featuring independent dual portion systems (one for the main grey concrete base, one for the colored pigment face).

• Hydraulic Assembly: Heavy-duty imported lever control valves paired with a high-capacity hydraulic oil reservoir.

• Pallet Product Capacity: Holds 24 Bricks or Interlocking Pavers per single drop cycle.

• Wooden Pallet Dimensions: 30 inches × 42 inches.

• Fluid & Operating Requirements: Requires a 600-liter hydraulic oil charge and 50 liters of industrial gear oil.

• Total Electrical Power Grid Load: 135 HP

  • Hydraulic Pump Motor: 30 HP

  • Vibration Table Motors: 40 HP ($20\text{ HP} \times 2$)

  • Mixer Machine Motors: 40 HP (30 HP Main Mixer + 10 HP Pigment Mixer)

  • Stacker & Conveyor System: 15 HP (Distributed across 5 HP, 2 HP, 3 HP, 2 HP, and 3 HP gear drives)

  • Batching Hopper Conveyor: 10 HP

4. SSM 35 Fully Automatic Double-Trolley Plant

A high-output commercial production center utilizing automated digital batching systems to achieve major output targets.

• Machine Operation System: Auto pallet and synchronized double-trolley raw material delivery system.

• Production Capacity: 80 to 100 pallets per hour.

• Molding Cycle Speed: 20 to 30 seconds per cycle.

• Pallet Product Capacity: Compresses 35 Rectangular Pavers or 35 Tuff Tiles per single stroke.

• Daily Production Yield: Generates an impressive 24,000 Premium Bricks/Blocks per standard 8-hour operational shift.

• Supported Product Height: 50mm to 200mm.

• Fluid Requirements: Requires an 800-liter industrial hydraulic oil reservoir.

• Total Electrical Power Grid Load: 131 HP

  • Vibration Table Motors: 40 HP ($20\text{ HP} \times 2$)

  • Hydraulic Pump Motor: 30 HP

  • Dual Mixer Motors: 40 HP (Combined 10 kW + 30 kW setup)

  • Material Conveyors: 11 HP (3 HP + 3 HP + 3 HP + 5 HP)

  • Automated Product Stacker: 10 HP (5 HP + 3 HP + 2 HP)

5. SSM 50 Industrial Flagship Plant

The ultimate, high-capacity powerhouse manufactured by Silver Steel Mills for national mega-projects, CPEC works, and major commercial ready-mix suppliers.

• Machine Operation System: Premium fully automated double-trolley layout utilizing full digital PLC touch-screen operating systems and automatic load-cell weighing scales.

• Production Capacity: 80 to 100 heavy-format pallets per hour.

• Molding Cycle Speed: Fast-acting 20 to 30 second compression and shake intervals.

• Pallet Product Capacity: Drops 50 Rectangular Pavers or 36 Standard Concrete Bricks (Dimensions: 228mm × 110mm × 76mm) per single machine stroke.

• Daily Production Yield: Delivers up to 40,000 Interlocking Pavers or Bricks in a single standard shift.

• Fluid Requirements: Large-scale 800-liter hydraulic oil tank complete with an integrated forced-chiller cooling radiator system.

• Total Electrical Power Grid Load: 161 HP

  • Vibration Table Motors: 60 HP ($30\text{ HP} \times 2$ deep-penetration vibration core)

  • Hydraulic Pump Motor: 40 HP

  • Industrial Mixer Drive: 40 HP (10 kW + 30 kW compulsory configuration)

  • Material Conveyors: 11 HP

  • Heavy-Duty Stacker Unit: 10 HP

Operational Workflow of a Turnkey Automatic Plant

To maintain high production speeds without bottlenecking, an SSM plant integrates several stages into a single continuous loop:

  [ AUTOMATED BATCHING HOPPERS ] ──> [ REINFORCED CONVEYOR ] ──> [ COMPULSORY MIXER CORE ]
                                                                             │
  [ AUTOMATED CURED STACKING ]   <── [ HYDRAULIC PRESS / MOLD ]  <─── [ OVERHEAD FEEDER ]

1. Digital Batching Zone: Sand, aggregate dust, and fly ash are loaded into automated batching bins. Built-in electronic load cells weigh each material precisely according to the pre-programmed mix design.

2. Compulsory Mixing Zone: The measured aggregates move up a heavy belt conveyor into a twin-shaft or pan mixer. Cement and water are added automatically to ensure a homogeneous, zero-slump concrete blend.

3. Molding & Compression Zone: The wet mix travels into the machine’s primary hopper and fills the lower die mould. The machine applies intense downward hydraulic pressure (up to 10,000 PSI) combined with high-frequency table vibration, removing all air pockets to pack the concrete tightly within seconds.

4. Automatic Stacking: The freshly pressed blocks travel forward on their wooden pallets into the automated stacker machine. The stacker groups the pallets vertically, making it easy for forklifts to safely transport them to the curing yard.

Project Feasibility: The Financial & Environmental Payback (SSM 35 Case Study)

Investing in an automated concrete block plant provides strong commercial returns compared to running an old-style clay brick kiln. Data from the SSM 35 Pre-Feasibility Study highlights the clear financial advantages for investors in Pakistan:

• Daily Production Output: Based on a conservative single-shift schedule producing 24,000 fly ash bricks a day (with an estimated target of 500,000 bricks per month over 25 operational working days).

• Manufacturing Cost vs. Market Value: The exact cost of production averages Rs. 12 per brick (including cement, aggregates, fly ash, labor, electrical power, and machinery depreciation). These units sell easily at a factory-gate price of Rs. 16 per brick.

• Monthly Profit Profile: This margins-to-volume ratio yields a consistent net daily income of Rs. 80,000, translating to a monthly net operating income of Rs. 2,000,000.

• Capital Investment Recovery: With a monthly operational budget of approximately Rs. 855,000 covering professional operators, loaders, fuel, and scheduled field maintenance, the entire initial capital expenditure achieves a payback period of just 15 months.

Beyond strong financials, automated block plants offer full regulatory compliance. Traditional brick kilns face frequent government closures during winter smog seasons to control air pollution. SSM automated concrete block machines run on clean electrical power and generate zero toxic smoke emissions. By actively recycling industrial waste like fly ash into valuable building materials, your business remains insulated from environmental shutdowns, ensuring steady, year-round revenue.

Partner with Pakistan’s Trusted Machinery Experts

Investing in automated block machinery is a major, long-term business decision. Partnering with an experienced local manufacturer like Silver Steel Mills gives you a clear competitive advantage:

• World-Class Engineering, Local Prices: We handle all structural cutting, heavy hydraulic assembly, and electrical control panel programming in-house, allowing us to offer high-output, durable plant setups at a fraction of the cost of expensive imported foreign machinery.

• Immediate Local Spare Parts Support: You never have to worry about long customs delays or dealing with overseas suppliers for basic maintenance. We keep a complete inventory of certified replacement parts—including custom CNC molds, replacement conveyor rollers, load cells, and hydraulic seals—right here in Pakistan for rapid support.

Whether you’re launching a new construction venture or upgrading your existing facility, our block making machines in Pakistan offer exceptional quality, competitive pricing, and nationwide support.

Why Choose Silver Steel Mills Block Making Machines?

Silver Steel Mills stands out in Pakistan’s construction machinery market due to:

• Superior Engineering Design

• Locally Manufactured Spare Parts

• Advanced Technology with Durable Build

• After-Sales Support & Service

• Affordable Prices with High ROI

We manufacture a complete range of machines for hollow blocks, solid blocks, pavers, and curb stones, tailored for different scales of production.

Popular Models of Block Making Machines by Silver Steel Mills

1. SSM-15 Block Making Machine

✅ Ideal for medium-scale manufacturers looking for durable performance and customizable output.

2. SSM-24 Automatic Block Making Machine

✅ Perfect for industrial-scale manufacturers who want speed, consistency, and lower labor dependency.

3. SSM-35 Industrial Block & Paver Machine

✅ Best suited for mega infrastructure and government contractors.

Applications of Silver Steel Mills Block Machines

• Housing Schemes

• Road & Highway Construction

• Paver Manufacturing

• Industrial Warehouses

• Municipal Development Projects

Block Making Machine Price in Pakistan

The block making machine price in Pakistan varies depending on:

• Production capacity

• Level of automation (manual/semi/automatic)

• Features (mixer, molds, hydraulic system)

• Raw material compatibility

At Silver Steel Mills, our block machine prices start from PKR 9.5 Lakh for semi-automatic models, going up to PKR 45 Lakh for fully automated industrial lines.

We offer the best value for money — no compromise on strength, consistency, or technology.

Nationwide Delivery and Support

Silver Steel Mills provides installation, training, and spare part support in major cities like:

• Lahore

• Karachi

• Islamabad

• Peshawar

• Multan

• Gujranwala

• Sialkot

Our team ensures your machine is delivered, installed, and operational in the shortest possible time.

Benefits of Using Silver Steel Mills Block Machines

• High Output with Less Power

• Less Labor, More Automation

• Low Maintenance Design

• 24/7 Technical Support

• Mold Customization on Demand

FAQs – Block Making Machines in Pakistan

Q: Can I use the machine for pavers and blocks both?
A: Yes, all our machines are designed for multi-product molds.

Q: What raw materials are compatible?
A: Cement, sand, gravel, fly ash, slag, and more.

Q: Is training provided?
A: Yes, our technical team trains your staff on machine operation and troubleshooting.

Q: Can I get molds customized for my block size?
A: Absolutely! We offer complete mold customization.

Q: How long does delivery take?
A: 5 to 10 working days depending on location and model.

Final Words: Choose Silver Steel Mills – The Future of Block Making in Pakistan

With Silver Steel Mills, you’re not just buying a machine — you’re investing in long-term construction efficiency, quality, and profitability. Our block making machines in Pakistan are built to withstand the toughest conditions and deliver high performance with every cycle.

Concrete Block Making Machines: Pakistan mein Karobar ka Aik Naya Inqilab

Pakistan ki construction industry mein ab bhatte ki eent (red bricks) ka istemal kam aur Concrete Blocks ka trend tezi se barh raha hai. Housing societies hon, industrial plazas hon ya sarkon ke kinare lagne wali Tuff Tiles—har jagah modern machinery ki zaroorat hai.

Silver Steel Mills Pakistan ka wo wahid naam hai jo na sirf machines banata hai, balkay aapko aik mukammal industrial setup farahum karta hai. Hamari machines apni mazbooti, speed aur kam maintenance ki wajah se poore Pakistan mein mashhoor hain.

Hamari Block Making Machines ki Categories

Hum ne har level ke investor aur businessman ke liye mukhtalif models design kiye hain:

1. Manual aur Semi-Automatic Models (SSM 15 & SSM 18)

Ye machines un logon ke liye behtareen hain jo thori sarmaya kari (investment) se apna kaam shuru karna chahte hain.

• Production: 100 se 110 pallets per hour.

• Khosusiyat: Single trolley system aur asaan operating system.

• Istemal: Small scale contractors aur local block providers ke liye behtareen.

2. Fully Automatic Models (SSM 24 Block machine in pakistan)

Ye models “Batching System” ke saath aate hain, yani material ki mixing se lekar block banne tak ka kaam computerised control panel (PLC) ke zariye hota hai.

• Double Layer System: In machines mein double trolley hoti hai jo Tuff Tiles aur Pavers par pigment (color) lagane ke liye behtareen hai.

• Efficiency: Kam mazdooron ke saath zyada production.

3. Heavy Industrial Plants (SSM 35 & SSM 50)

Ye hamare sab se baray plants hain jo mega projects ke liye istemal hote hain.

• SSM 35: 140 pallets per hour tak ki capacity.

• SSM 50: Din mein 40,000 rectangle pavers banane ki salahiyat.

• Spec: In mein 10,000 PSI tak ka hydraulic pressure hota hai jo block ko pathar jaisa sakht bana deta hai.

Technical Specs jo Humien Mumtaz Banati Hain

Humari machines ki lambi umar ka raaz un ke material mein chupa hai:

• Imported Steel: Hum Q235 MS Imported Sheet aur SS Chrome Shafts istemal karte hain.

• Hydraulic Power: 21-gallon ke heavy-duty pumps aur cooling system taake machine lagatar 24 ghante chal sake.

• Vibration Technology: High-frequency vibration motors jo material ko achi tarah compact (press) karti hain.

• Precision: Har machine CNC machining aur engraving ke zariye banai jati hai taake har block ka size bilkul barabar ho.

Block Making Business: Munafa aur Scope

Agar aap ye karobar shuru karte hain, to aap ko munafe ke mutalliq pareshan hone ki zaroorat nahi:

1. Raw Material ki Asani: Cement, crush aur rait har shehar mein ba-asani mil jati hai.

2. Kam Production Cost: Machine ke zariye banne wala block eent ke muqable mein sasta parta hai aur is ki deewar jaldi khari hoti hai.

3. Har Mausam mein Kaam: Bhatta barish mein band ho jata hai, lekin block plant shed ke neeche poora saal chalta hai.

Silver Steel Mills se Machine Kyun Kharidien?

Hum sirf machine farahum nahi karte, balkay humara sath installtion ke baad bhi rehta hai:

• 3 Month Free Service: Hum 3 mahine tak free technical service farahum karte hain.

• Trained Workers: Hum aapke plant ke liye expert operator aur labor recommend karte hain.

• Foundation Layout: Plant lagane se pehle hum civil work ka mukammal naksha (layout) dete hain.

• Customization: Aap apni zaroorat ke mutabiq Die (Mould) banwa sakte hain—chahe wo Hollow block ho, Solid block ho ya zigzag tuff tile.

Aksar Pooche Janay Walay Sawalat (FAQs)

Q: Kya Silver Steel Mills poore Pakistan mein delivery deta hai? A: Ji bilkul, hum factory se loading aur transportation manage kar sakte hain, jo buyer pay karta hai.

Q: Machine chalane ke liye kitni bijli ki zaroorat hoti hai? A: Model ke hisab se 60 HP se lekar 160 HP tak ka load darkar hota hai. Hum energy-efficient motors istemal karte hain taake bijli ka kharcha kam aye.

Q: Ek machine se kitne qism ke blocks ban sakte hain? A: Aap sirf “Die” change kar ke aik hi machine se 10 se zyada qism ke designs (Bricks, Tiles, Blocks) bana sakte hain.

Pakistan Me Block Making Machine Ka Karobar: Silver Steel Mills Ki High-Quality Models

Aaj kal Pakistan me construction ka kaam itni tezi se barh raha hai ke sasti aur mazboot bricks (eento) ki demand kabhi khatam nahi hoti. Agar aap aik aisa karobar talaash kar rahe hain jo saal ke 12 mahine chale, to Concrete Block Making Machine aik behtareen investment hai.

Lekin sawal ye hai ke machine kahan se li jaye? Pakistan ki market me Silver Steel Mills aik aisa naam hai jo sirf machine bechta nahi hai, balkay apko aik mukammal setup bana kar deta hai.

1. Silver Steel Mills Hi Kyun? (Real Experience)

Market me halki chadar aur purani motors wali sasti machines bohat hain, jo do mahine baad vibrate ho kar phat jati hain. Silver Steel Mills ki machines ki khasiyat unka Heavy-Duty Structure hai.

• Mazboot Material: Humari machines me high-grade steel use hota hai jo heavy vibration bardasht karta hai.

• Precision Engineering: Block ka size 19-20 nahi hota, har block ek jesa nikalta hai.

• Customer Support: Machine lagane se lekar chalane tak, Silver Steel Mills apne clients ko guide karta hai.

4. Block Business Me Profit Kitna Hai?

Chalein thora hisab lagate hain (Andazan):

• Aik standard 4x8x12 block banane ki cost (material + bijli + mazdoori) takreeban Rs. 35-45 tak aati hai.

• Market me yehi block Rs. 55-70 tak sale hota hai.

• Agar aap din ke 2,000 blocks bhi banayein, to kharcha nikal kar aik din ka Rs. 20,000 se 30,000 tak munafa mumkin hai.

5. Silver Steel Mills Buyer Guide: Machine Lene Se Pehle Ye Check Karein

Jab bhi aap hamare paas ya kisi bhi manufacturer ke paas jayein, ye 3 cheezein zaroor dekhein:

1. Vibration System: Kya vibration pure mould par barabar hai? Agar nahi, to block kacha rahega.

2. Hydraulic Press: Kya pressure itna hai ke block andar se khokla na rahe?

3. Mould Quality: Mould ki plate ki thickness check karein, yehi machine ki jaan hoti hai.

Frequently Asked Questions (FAQs)

Q1: Kya ye machine single-phase bijli par chal sakti hai?

Ji haan, humari small aur medium machines ko hum single-phase motors par bhi customize kar sakte hain taake aap ghar ya choti jagah se kaam shuru kar sakein.

Q2: Machine ki warranty kya hoti hai?

Silver Steel Mills apni har machine ke structure aur major components par technical warranty deta hai.

Q3: Kya blocks, eento (Red Bricks) se behtar hain?

Bilkul! Blocks lagane me waqt kam lagta hai, cement kam kharch hota hai, aur ye garmiyon me kamra thanda rakhte hain. Isi liye log ab blocks ki taraf shift ho rahe hain.

Q4: Delivery poore Pakistan me mil jayegi?

Ji bilkul, Karachi se Gilgit tak humari machines deliver hoti hain aur humara technician setup ke liye sath jata hai.

Conclusion
